KT200II ECU Label Documentation Guide Before Programming
Accurate ECU identification is the first step toward selecting a compatible KT200II programming protocol. Clear photographs and complete records help technicians avoid incorrect vehicle, hardware, or connection choices.
Why ECU Label Documentation Matters
Many vehicles use more than one ECU hardware family during the same model generation. Engine type, transmission, production year, market version, software calibration, and supplier can all affect the correct programming method. The vehicle name alone is not enough to confirm compatibility.
Before using the official KT200II ECU programmer, record the identification information printed on the module. This information can then be compared with the KT200II supported vehicle database.
What to Photograph on the ECU
Main Identification Label
Capture the complete label, including manufacturer, part number, hardware number, software number, barcode, and serial information.
Connector Side
Take a clear image of every connector and its orientation. Connector shape and pin position can help confirm the ECU family.
Housing and Markings
Photograph casting marks, revision codes, warning labels, security seals, and any previous repair marks.
Vehicle Context
Record the vehicle identification information and take a wider photo showing where the ECU was installed.
ECU Data Fields to Record
| Data Field | What to Record | Why It Helps |
|---|---|---|
| Vehicle | Brand, model, year, engine, transmission | Narrows the compatible support records |
| ECU identity | Supplier, ECU type, part number, hardware number | Distinguishes similar modules |
| Software data | Software number, calibration code, revision | Supports file and version selection |
| Service objective | Backup, replacement, cloning, repair, or programming | Clarifies the required workflow |
Photo Quality Checklist
- Clean dust and oil from the label without damaging printed markings.
- Use even lighting and avoid reflections from glossy labels.
- Take one full-module photo and separate close-ups for small text.
- Keep the label flat and make sure all four edges are visible.
- Photograph connector orientation before disconnecting the module.
- Use a consistent filename, such as
brand_model_ecu-part-number_date. - Store the original images with the customer job record.
Match the ECU Record With the KT200II Support List
After documenting the module, search the support database using a combination of terms instead of only the vehicle name. Useful combinations include the brand plus ECU type, part number, processor, or connection method. Confirm the ECU/TCU category, microcontroller or EEPROM information, and the listed read/write connection.
Do not assume that every ECU supports every KT200II operation mode. Review the official OBD, Bench, Boot, JTAG and BDM operation guide before making a connection.
Choose the Connection Method From the Record
| Mode | Typical Access | Documentation Check |
|---|---|---|
| OBD | Vehicle diagnostic port | Confirm vehicle and protocol support |
| Bench | Direct ECU connection | Confirm ECU part number and adapter method |
| Boot | Deeper microcontroller access | Confirm processor, pinout, and supported procedure |
| JTAG / BDM | Selected direct programming interfaces | Confirm interface availability for the exact ECU |
A Practical Documentation Workflow
- Photograph the installed ECU and record the vehicle details.
- Photograph all labels, connectors, and housing markings.
- Transcribe the important numbers into the job record.
- Search the official KT200II support list.
- Confirm the required operation mode and accessories.
- Install the correct package from the KT200II software download page.
- Save the original photos and read data before writing a file.
Common Documentation Mistakes
- Recording only the vehicle model and ignoring the ECU part number.
- Saving a cropped label photo that omits the hardware or software code.
- Mixing photos from different vehicles in the same folder.
- Choosing OBD, Bench, or Boot mode before checking the exact support record.
- Overwriting original images after a replacement ECU is installed.
